Discover machines suitable for every need.
Max outreach, m:
4.2
Telescopic boom stroke length, m:
1,2
Crane weight without support leg and valve block, kg:
185
Max outreach, m:
4,2
Brutto lifting torque 190 bar, kNm:
26
Telescopic boom stroke length, m:
-
Crane weight without support leg and valve block, kg:
360
Max outreach, m:
5,4
Brutto lifting torque 190 bar, kNm:
26
Telescopic boom stroke length, m:
1,33
Crane weight without support leg and valve block, kg:
400
Max outreach, m:
6,3
Brutto lifting torque 190 bar, kNm:
36
Telescopic boom stroke length, m:
1,85
Crane weight without support leg and valve block, kg:
415
Max outreach, m:
6,7
Brutto lifting torque 190 bar, kNm:
41
Telescopic boom stroke length, m:
1,85
Crane weight without support leg and valve block, kg:
620
Max outreach, m:
7,1
Brutto lifting torque 190 bar, kNm:
50
Telescopic boom stroke length, m:
1,95
Crane weight without support leg and valve block, kg:
710
Max outreach, m:
7,5
Telescopic boom stroke length, m:
2,0
Crane weight without support leg and valve block, kg:
940
Max outreach, m:
8,5
Brutto lifting torque 190 bar, kNm:
56
Telescopic boom stroke length, m:
3,3
Crane weight without support leg and valve block, kg:
900
Max outreach, m:
8,7
Telescopic boom stroke length, m:
3,3
Crane weight without support leg and valve block, kg:
995
Max outreach, m:
7,8
Brutto lifting torque 190 bar, kNm:
74
Telescopic boom stroke length, m:
2,15
Crane weight without support leg and valve block, kg:
1220
Max outreach, m:
8,6
Brutto lifting torque 190 bar, kNm:
74
Telescopic boom stroke length, m:
3,4
Crane weight without support leg and valve block, kg:
1280
Max outreach, m:
9,4
Telescopic boom stroke length, m:
3,8
Crane weight without support leg and valve block, kg:
1310
Max outreach, m:
10,1
Telescopic boom stroke length, m:
4,2
Crane weight without support leg and valve block, kg:
1760
Cranes |
PALMS 1.42 | PALMS 2.42 | PALMS 2.54 | PALMS 3.63 | PALMS 3.67 | PALMS 4.71 | PALMS 5.75 | PALMS 5.85 | PALMS 5.87Z | PALMS 7.78 | PALMS 7.86 | PALMS 7.94 | PALMS X100 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Series | 1 | 2 | 2 | 3 | 3 | 4 | 5 | 5 | 5 | 7 | 7 | 7 | X |
| Max outreach, m | 4.2 | 4,2 | 5,4 | 6,3 | 6,7 | 7,1 | 7,5 | 8,5 | 8,7 | 7,8 | 8,6 | 9,4 | 10,1 |
| Telescopic boom stroke length, m | 1,2 | - | 1,33 | 1,85 | 1,85 | 1,95 | 2,0 | 3,3 | 3,3 | 2,15 | 3,4 | 3,8 | 4,2 |
| Slewing cylinder amount in slewing housing, pcs | 2 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Slewing torque, kNm | 2,1 | 7,8 | 7,8 | 9 | 12 | 15 | 17 | 17 | 17 | 21 | 21 | 21 | 30 |
| Working pressure, bar | 180 | 190 | 190/215 | 190 | 190/215 | 190/215 | 190/215 | 190/215 | 215 | 190/215 | 190/215 | 215 | 240 |
| Rotator maximum load, kN | 10 | 45 | 45 | 45 | 45 | 45 | 60 | 60 | 60 | 60 | 60 | 60 | 100 |
| Crane weight without support leg and valve block, kg | 185 | 360 | 400 | 415 | 620 | 710 | 940 | 900 | 995 | 1220 | 1280 | 1310 | 1760 |
| Pillar slewing angle, degrees | 330 | 370 | 370 | 370 | 370 | 370 | 380° | 380 | 340 | 380 | 380 | 380 | 380 |
| Lifting capacity at full reach, 240 Bar, w/o grapple and rotator, kg | - | - | - | - | - | - | - | - | - | - | - | - | 680 |
| Lifting capacity at full reach, 215 Bar, w/o grapple and rotator, kg | - | - | 410 | - | 480 | 580 | 620 | 520 | 490 (8.4 m) | 670 | 630 | 540 | - |
| Lifting capacity at full reach, 190 Bar, w/o grapple and rotator, kg | - | 540 | 370 | 355 | 430 | 490 | 540 | 450 | - | 580 | 530 | - | - |
| Lifting capacity at 4 m, 240 Bar, w/o grapple and rotator, kg | - | - | - | - | - | - | - | - | - | - | - | - | 2000 |
| Lifting capacity at 4m, 215 Bar, w/o grapple and rotator, kg | - | - | 600 | - | 910 | 1115 | 1350 | 1220 | 1235 | 1580 | 1480 | 1410 | - |
| Lifting capacity at 4m, 190 Bar, w/o grapple and rotator, kg | - | 570 | 530 | 655 | 820 | 965 | 1150 | 1050 | - | 1380 | 1250 | - | - |
| Brutto lifting torque 240 Bar, kNm | - | - | - | - | - | - | - | - | - | - | - | - | 106 |
| Brutto lifting torque 215 Bar, kNm | - | - | 29 | - | 46 | 56 | - | 63 | 63 | 83 | 83 | 83 | - |
| Brutto lifting torque 190 bar, kNm | - | 26 | 26 | 36 | 41 | 50 | - | 56 | - | 74 | 74 | - | - |
| Recommended oil flow, L/min | - | 20-35 | 20-35 | 20-35 | 30-45 | 45-70 | 50-90 | 50-90 | 50-90 | 60-120 | 60-120 | 60-120 | 120 |
